Global Hawk, LLC's One of a Kind "World Famous OGI-Ventus Gas Inspection Camera" & it's specs & Visible Carbon Based Gases

The Ventus OGI-Camera UAS Payload is built directly into the DJI Pilot App and is integrated directly through the Software. this allows the UAS Ventus OGI-Camera System to operate flawlessly as a Plug-n-Play system into any DJI Matrice 300 RTK Enterprise Drone System right off the shelf.

Our UAS Payload for the Matrice 300 RTK Enterprise called the "Ventus™ OGI (Optical Gas Imaging) camera", this Ventus OGI-Camera core brings together the very latest in detector, cooler and lens design for optimizing the detection and visualizing of hydrocarbon gas leaks such as methane, propane, butane and many other gases. The combination of these start of the art components produces the smallest, lightest and lowest powered OGI camera core in the market today which makes it ideal for integrating into gimbals or enclosures for unmanned aerial vehicle platforms or fixed mounted, continuous monitoring systems.

The Ventus™ OGI utilizes a new state-of-the-art 640 x 512, 15µm pixel pitch “Hot MWIR” detector array with a special narrow bandpass cold filter in a miniature, long life, closed cycle, sterling cooler with an f/1.5 cold shield and an optimized purpose built lens to provide unmatched thermal sensitivity.

Weighing in at only 475 grams with a lens and with dimensions of 146.6 x 70.9 x 73.1 the Ventus™ OGI makes this an easy choice for OEM’s and integrators. The Ventus™ cores are available with a choice of digital and analog inputs and outputs including Camera Link, Gigabit Ethernet, H.264, NTSC/Pal video and RS-232/RS-422 serial camera control. The camera core also has advanced image processing features such as Local Area Processing,-Dynamic Contrast Enhancement, Noise Reduction Filter, Foreground and Background Boost Contrast, automatic gain and level control, 2x, 4X and 8x electronic zoom, multiple color palettes and up to six calibration tables for different scene and contrast lighting conditions.
